HCFU Series - Standard Duty, eccentric Locking Collar Type
- Standard duty square flange unit
- Eccentric locking collar
- Cast-iron housing
- Wide inner ring bearing
- Dual heavy-duty slinger type contact seals
- Anti-Rotation device
- Triple lip seals (R3 suffix) optional
| Specifications: | |
|---|---|
| Unit No. | HCFU203-17MM |
| Bearing Type | Standard Duty Square Flange Unit, Eccentric Locking Collar |
| Material | Cast Iron Housing, AISI 52100 steel insert |
| Shaft Diameter | 17 mm |
| Insert No. | HC203-17MM |
| Housing No. | FU204 |
| Basic Dynamic Load Rating (Cr) | 2877.55 lbs |
| Basic Static Load Rating (Cor) | 1494.98 lbs |
| Weight | 1.54 lbs |
