SAF Series - Light Duty, Eccentric Locking Collar Type
- Light duty square flange unit
- Eccentric locking collar
- Cast-iron housing
- Narrow inner ring bearing
- Full cover metal-shroud seals
| Specifications: | |
|---|---|
| Unit No. | SAF206-19G |
| Bearing Type | Light duty square flange unit, eccentric locking collar |
| Material | Cast Iron Housing, AISI 52100 steel insert |
| Shaft Diameter | 1.1875 in |
| Insert No. | SA206-19G |
| Housing No. | F206 |
| Basic Dynamic Load Rating (Cr) | 4383.77 lbs |
| Basic Static Load Rating (Cor) | 2540.34 lbs |
| Weight | 2.56 lbs |
Technical Information
Part number nomenclature
Construction
Tolerance
Grease Types
Grease Fittings
Relubrication
