UC Series - Standard Duty, Setscrew Locking Type
- Standard duty, set screw locking
- Spherical OD self-aligns in outer housing
- Wide inner ring
- Lubrication groove with hole on set screw side
- Dual heavy-duty slinger type contact seals
- Anti-rotation device
- Triple lip seals (R3 suffix) optional
- Also available in free-spinning design and/or with black oxide finish
| Specifications: | |
|---|---|
| Unit No. | UC205-15 |
| Shaft Diameter | 0.9375 in |
| Outer Diameter | 2.0472 in |
| Width | 1.3400 in |
| Outer Ring Width | 0.6693 in |
| Dynamic load ratings | 3147.33 lbs |
| Static load ratings | 1764.75 lbs |
Technical Information
Part number nomenclature
Construction
Tolerance
Grease Types
Grease Fittings
Relubrication
