SBP Series - Light Duty, Set Screw Locking Type
- Light duty unit, set screw locking
- One-piece cast iron housing, solid base
- Narrow inner ring bearing
- Full cover metal-shroud seals
- Steel plate slingers on sides for dust exclusion
- Grease fitting for adding lubricant
- Anti-Rotation device
| Specifications: | |
|---|---|
| Unit No. | SBP201-8G |
| Bearing Type | Pillow Block - Light duty unit, set screw locking |
| Material | Cast Iron Housing, AISI 52100 steel insert |
| Shaft Diameter | 0.5000 in |
| Insert No. | SB201-8G |
| Housing No. | P203S |
| Basic Dynamic Load Rating (Cr) | 2158.17 lbs |
| Basic Static Load Rating (Cor) | 1034.12 lbs |
| Weight | 1.38 lbs |
Technical Information
Part number nomenclature
Construction
Tolerance
Grease Types
Grease Fittings
Relubrication
