UCP Series - Standard Duty, Set Screw Locking Type
- Standard duty unit, set screw locking
- One-piece cast iron housing, solid base
- Wide inner ring bearing
- Dual heavy-duty slinger type contact seals
- Grease fitting for adding lubricant
- Anti-Rotation device
- Triple lip seals available on request
| Specifications: | |
|---|---|
| Unit No. | UCP205-25MM |
| Bearing Type | Pillow Block - Standard duty unit, set screw locking |
| Material | Cast iron housing, AISI 52100 steel insert |
| Shaft Diameter | 25 mm |
| Insert No. | UC205-25MM |
| Housing No. | P205 |
| Basic Dynamic Load Rating (Cr) | 3147.33 lbs |
| Basic Static Load Rating (Cor) | 1764.75 lbs |
| Weight | 1.79 lbs |
Technical Information
Part number nomenclature
Construction
Tolerance
Grease Types
Grease Fittings
Relubrication
