UCPSS Series - Stainless Steel Pillow Blocks
- Corrosion resistant units for clean operating environments, frequent washdowns
- Use for food processing, packaging, pharmaceutical production, handling
- High quality 304 stainless steel housings
- Wide inner ring bearings
- Solid base, smooth polished surfaces
- Lubricated with food grade grease
| Specifications: | |
|---|---|
| Unit No. | UCPSS204-20MM |
| Bearing Type | Standard duty unit, set screw locking |
| Material | Stainless Steel |
| Shaft Diameter | 20 mm |
| Insert No. | SSUC204-20MM |
| Housing No. | SP204 |
| Basic Dynamic Load Rating (Cr) | 2302 lbs |
| Basic Static Load Rating (Cor) | 1495 lbs |
| Weight | 1.46 lbs |
